Bariatric Operating Table
Model: DST-700 Name: bariatric operating table Introduction The superb YUDA DST-700 series operating table can use for imaging diagnosis and checking, also use for various operations. It has a horizontal 350mm (13.8in) movements, supply accurate and convenient space for C-arm, can get X-ray...
Name: bariatric operating table
The superb YUDA DST-700 series operating table can use for imaging diagnosis and checking, also use for various operations. It has a horizontal 350mm (13.8in) movements, supply accurate and convenient space for C-arm, can get X-ray imaging of full body without moving the patient.
YUDA medical R&D the carbon fiber material, it is high clear imaging results, low X-ray absorption. It can put the head support to leg board, to extend the end part for operations of lower parts of body.
Adopts the Germany DUKERON micro-motor, with electric gear mesh mechanism structure instead of the traditional hydraulic transmission. Germany beeline navigation rail, ensure the smooth movement.
1.Extreme Load Capacity---Maximum capacity 430 kg / 950 lbs.
2.Horizontal movement for X-ray Compatibility
Motorized longitudinal shift of up to 350 mm (13.8 in) and the use of carbon-fiber modules provide excellent C-arm access.
The height adjustment from 660 to 1000 mm (25.9 to 39.3 in) permits ergonomic working positions, both seated and standing.
4..Gynecology and Urology, bariatric, Neurosurgery can be finished by this type OT table.
5.Optional: temperature warm function.
Bed Panel Size (full carbon fiber material)
(2020 x 535) ± 10mm
Bed height from the ground (Without pads)
Min height: (695 ± 20) mm
Lifting up and down (electric)
(300 ± 20) mm
Horizontal move route(electric)
(330 ± 20) mm
Head and foot tilt (electric)
Head tilt: 30° ± 2 °
Foot tilt: 30° ± 2 °
Lateral tilt (electric)
Left: 25° ± 2 °
Right: 25° ± 2 °
Back plate fold (electric)
Upward: 65 ° ± 2 °
Downward: 20 ° ± 2 °
Leg plate fold (manual)
Upward: 35 ° ± 5 °
Downward: 90 ° ± 5 °
Head section fold (manual)
Upward: 45 ° ± 5 °
Downward: 90 ° ± 5 °
One key reset function
One week (80-100 times)
Table panel X-ray absorption coefficient
AC: 220V 50Hz 300VA
DC: 24V (Panasonic lead-acid batteries)
Net weight /capacity weight
300kg (661lbs) /430kg( 950lbs)
