Hydraulic Operation Theatre Table

Model: DST-III Name: hydraulic operation theatre table Introduction DST-III is a modern surgical equipment with a high advanced performance, it can finish head and leg board exchange, with advanced Germany Dukermoteron, and Taiwan hydraulic system,it can bear 430kg( 947lbs) maximum capacity.With...

Send InquiryChat Now

Model: DST-III
Name: hydraulic operation theatre table

 Introduction
 DST-III is a modern surgical equipment with a high advanced performance, it can finish head and leg board exchange, with advanced Germany Dukermoteron, and Taiwan hydraulic system,it can bear 430kg(  947lbs) maximum capacity.With its versatile table tops, the DST-III can be use across all surgical disciplines.



 Features

 1.it adopts the Germany Dunker motor, with electric hydraulic transmission, more flexible for movements.

 2.The bed panel back plate is made of carbon fiber material to reduce X ray absorption. It extens the lifetime of spheroid tube and main parts of video machine, and reduce the radiation damage to patients and paramedic.

 3. With tilt function of trendelenburg, which is specially designed for ERCP, the doctors can achieve the perfect imaging with no need to move the  patient.

 4.German beeline navigation rail ensures sommth and steady movement of the operating table.

 5.Base with ABS industrial plastic, helps prevent glare and impact to doctors during operation, Besides, it is easy to clean and disinfect after operation.

 6. Handle control is easy to operate, with indicators of each function. The brake system is safe and senstive.

 7.Backup battery is availble for choise,and it can last for one week with full charge(50- 8.operations) while power off.



 Technical data
 >Bed Panel Size: (2015x 540) ± 10mm ( 79* 21.3in)
 >Bed height from the ground(without pads):Min height: (660 ± 20) mm
 Max height: (1000 ± 20) mm(26-40.1in)
 >Lifting route (electric):(340 ± 20) mm (14.1in)
 >horizontal route(electric):(350 ± 20) mm(14.2in)
 >Head and foot tilt (electric):Head down tilt: 25 °, Foot down tilt:25 °
 >Lateral tilt (electric):Left: 22° ,Right: 22 °
 >Back plate fold(electric):Upward: 70 °,Downward:32 °
 >Leg plate fold (manual):Upward: 28 °,Downward: 90 °
 >Head section fold (manual):Upward: 30 °,Downward:90 °
 >Table panel X-ray absorption coefficient:≤ 0.44mmAL
 >Power supply:220V 50Hz 300VA
 >Net weight/ capacity weight:260kg / 430kg (950lbs)
 >Lifting route (electric)
 FAQ

 1.What is your payment term?
 A:L/C at sight;T/T:30% deposit by T/T,70% balance by T/T before shipment.
 2.What is your min.order?
 A:There's no minimum quantity.
