Model: DST-500A

Name: surgical table accessories

 Introduction
 DST-500A can be best support your financial cost with a high excellent using experience. Offers many features and a large range of positioning possibilities as well as it has a basic function for  radiolucent imaging .
 Mobile universal operating table DST-500A offers 300kg load capacity, maximum flexibility and maximum comfort. It is an economic OT table in all surgeons demands.







 Features
 1.horizontal movement: 320mm (12.6in), match up to X-ray imaging radiolucent.
 2 high strength X-ray fiber, main material is stainless steel for the full operating table body.
 3 Electric braking, with castors on the base.
 4.high intensity memory mattress.




Technical data

Bed Panel Size

2040 x 520mm

Bed height from the ground (without pads)

Min height: 850 mm
Max height: 1050mm

Lifting route (electric)

200 ± 20mm

Horizontal route (electric)

300 ± 20mm

head and foot tilt (electric)

head tilt: 20 ° ± 2 °

foot tilt: 20 ° ± 2 °

Lateral tilt (electric)

Left: 19°± 2 °

Right: 19°± 2 °

leg plate fold (manual)

downward:90 °

Horizontal extend: 90 °

back plate fold (electric)

upward:65°

Downward:30°

Head section fold (manual)

Upward:20° ± 2 °

Downward:90° ± 2 °

External kidney bridge lifting route(manual)

120 ± 10mm

Net weight/ capacity weight

170kg/ 300kg

Table locking

manual

Power supply

220V 50Hz 750VA
