Diagnostic Operating Table X Ray Bed
Radiolucent carbon fiber accessories improve intraoperative diagnostics that are critical to achieving optimal outcomes.YUDA Electrical Operation Table for radiology can be
matched with GE, SIMEONS, PHILIPS, ZIEMH for X ray photography table used for C-arm machine.YUDA is the only one factory with a 480,000 square meters,covers 38 workshop.
YUDA has the first digital control workshop in China.
YUDA medical group, since 1992. We have a world wide 200 emplyees and 3 offices, with many distributors.
Model: DST-700G
Name: Electric Orthopedic Imaging navigation operating table
warranty： 3 years
lifespan: 15-20 years
motor: German Dunkermotoren
DST-700G --It bears patient weight max up to 300kg ( 661 lbs), with a lower position comes to 680mm(267.71in), horizontal movement 260mm, permits ergonomic working positions, both seated and standing.
Except as an universal and orthopedic operating table, DST-700 has the super performance on Imaging navigation, with carbon fiber board, match up to GE, Philips, Siemens, Ziehm, ect C-arm machine.
Bed Panel Size | 2400 x 530mm (+/-10mm) |
Bed height from the ground (without pads) | Min height: 680 mm (+/-20mm) |
Lifting route (electric) | 320mm |
Horizontal route (electric) | 260mm |
head and foot tilt (electric) | head tilt: 25 ° ± 2 ° |
foot tilt: 25 ° ± 2 ° | |
Lateral tilt (electric) | Left: 22° ± 2 ° |
Right: 22° ± 2 ° | |
leg plate fold (manual) | downward: 90 ° |
upward: 35 ° | |
back plate fold (electric) | upward: 65° |
Downward: 20° | |
Head section fold (manual) | Upward: 45 ° |
Downward: 90° | |
Table panel X-ray absorption coefficient | ≤ 0.44mmAL |
CPR （one reset function) | Electric |
Net weight/ capacity weight | 300kg/ 320kg |
Table locking | Electric |
Power supply | 220V 50Hz 300VA |
